Vet Portable B/W Ultrasound Machine

Vet Portable B/W Ultrasound Machine

Model:MCV05787

Introducing the Vet Portable B/W Ultrasound Machine, a high-quality and convenient ultrasound scanner designed specifically for veterinary use. This portable ultrasound machine offers clear black and white imaging for accurate diagnosis and treatment. Ideal for on-the-go veterinarians, this vet ultrasound machine is a must-have for any animal healthcare professional.

Exclusive employ double waveform imaging technology Outstanding portable model,compact and

streamlined design Transducer auto-freeze protection

Biopsy function,THI,SRI,TSI,Smooth

Auto Optimize and Q Guide

All-round adjusting knob,efficient and fast

Support image magnification and full screen display

Support multiple measurement software package

Support PW mode and spectrum full screen display

Support multiple data transmission interface

Auto-generation BMP format report,support USB import and export.

Nonuse any special software to read or print on PC

Optional laser printer can print the generated report

1 System Overview

 1.1 Clinical Applications

 Dog

 Cat

 Sheep

 Swine

 Bovine

 Equine

 Donkey

 Camel

 Custom

 1.2 Transducer Types

 Convex transducer

 Linear array

 Trans-vaginal transducer

 Micro-convex transducer

 Rectal transducer

 1.3 Imaging modes

 B-Mode

 2B/4B-Mode

 M-Mode

 B/M-Mode

 PW-Mode

 1.4 Standard features

 B-Mode

 Tissue Specific Imaging (TSI)

 Tissue Harmonic Imaging (THI)

 B Chromatic imaging

 Pan-zoom

 2B/4B-Mode

 M-Mode

 Full Screen Imaging (FSI)

 B/M-Mode

 PW-Mode

 B/PW dual real-time

 PW FSI

 Speckle Reduction (SRF)

 12-inch color display screen

 2 transducer connectors

 2 USB ports

 Support Language: Chinese, English, Spanish, French, Russian, Turkish

 Automatic parameter saving (Zero button)

 One-click automatic parameter reset

 Built-in operational guidelines and tutorial

 Built-in specialist measurement kit

 1.5 Optional features

 Built-in Li-ion battery

 Laser/thermal printer

 Foot Switch

 Puncture

1.6 Image Saving

 Format: BMP

2. Physical Specification

 2.1 Dimension and weight

 Width: approx. 370mm

 Height: approx. 360mm

 Thickness: approx. 155 mm

 Weight: 6.2 Kg (Without battery)

 6.65Kg（with battery）

2.2 Monitor

 12-inch high resolution color display screen

 Resolution: 1024×768

 Tile Angle: 0-90°

 2.3 Transducer ports and holders

 2 transducer ports

 2 removable transducer holders

 2.4 Electrical power

 AC adapter Input

   Voltage: 100-240V~

   Frequency: 50/60Hz

   Power Consumption: 110VA

 Built-in Battery

 Lithium-ion rechargeable battery

 10.89V/5200mAh

 2.5 Operation Environment

 Ambient temperature: 5℃~+40℃

 Relative humidity: 25%~85%

 Atmospheric pressure: 700hPa~1060hPa

 2.6 Storage &Transport Environment

 Ambient temperature: -20℃~+55℃

 Relative humidity: 10%~95%

 Atmospheric pressure: 500hPa~1060hPa

2.7 Main body

 32MB SSD +8GB HDD

 Operating system -- Linux

3 User Interface

3.1 Control panel

 Power/Battery indicator

 Alphanumeric silica gel keyboard

 Function keys ¶meter shortcut key

 Back-lit keys

 Knobs: Value &Gain

 8-segment TGC control

 Trackball

3.2 System boot-up

 Boot-up in about 15s

 Shut down in about 8s

 3.3 Comments

 Support text input and arrow

 Arrow position and direction adjustable

 3.4 Body marks

 23 Animal icon

3.5 Screen information

 Common info:

    Logo

    Hospital name

    Display Parameters

   System date &Time

   Clinical application

   Transducer type

   Exam mode

   Patient Name, Age, Gender

   Transducer mark

   Thumbnail

   Focus position

   Parallel scale & Vertical scale

   Freeze mark

   TGC Curve

vet has excellent performance and different applications according to user's demands: Felidae, Canine, Ovine, Equine, Bovine, Swine, User-defined.
