Model No: MCV0422

Microplate Reader for Veterinary Laboratory

Introducing our Advanced Microplate Reader, a powerhouse of analytical capabilities designed to elevate your research and experimentation. With a focus on precision, speed, and user-friendliness, this reader is your ideal companion in the laboratory.
Quantity :
Contact Now

Microplate Reader for Veterinary Laboratory

Model: MCV0422



Microplate Reader Description:

Introducing our Advanced Microplate Reader, a powerhouse of analytical capabilities designed to elevate your research and experimentation. With a focus on precision, speed, and user-friendliness, this reader is your ideal companion in the laboratory.


Microplate Reader Features:

  1. Highly Accurate Optical Measuring System: The Microplate Reader is equipped with a cutting-edge optical measuring system that ensures the highest level of accuracy in your experiments.
  2. Rapid 8-Channel Reading: With its 8-channel configuration, this reader scans and analyzes an entire plate of samples in a mere 5 seconds, significantly expediting your research.
  3. Optional PC Software: Enhance your data analysis and management capabilities with optional PC software, streamlining your workflow and providing comprehensive insights.
  4. Integrated Microplate Shaking: Simplify your sample preparation process with the built-in microplate shaking function, ensuring thorough mixing for precise results.
  5. Intuitive Touch Screen and Large LCD Display: Navigate effortlessly with the intuitive touch screen and the large, easy-to-read LCD display, offering clear and convenient control.
  6. Versatile Plate Compatibility: The reader supports multiple plate formats, accommodating a wide range of experimental needs and sample sizes.
  7. Built-In Thermal Recorder: Maintain meticulous records of your experiments and results with the integrated thermal recorder.
  8. Customizable Calculation Methods: Tailor your calculations to meet the unique requirements of your experiments, whether qualitative or quantitative.
  9. On-Board Data Analysis: Benefit from on-board data analysis tools that simplify interpretation and reporting, ensuring the utmost accuracy in your results.
  10. Comprehensive Service Solutions: Enjoy a complete life cycle service solution, guaranteeing the optimal performance and longevity of your Microplate Reader.
  11. On-Site Troubleshooting: For complex issues, our on-site troubleshooting service offers swift resolutions, minimizing disruptions to your research.
  12. Trusted Spare Parts Suppliers: We partner with well-known spare parts suppliers renowned for their quality and reliability.
  13. High-Performance PCB Boards: The Microplate Reader is equipped with high-performance PCB boards, contributing to its overall functionality and reliability.
  14. Stringent Quality Control: Every single component undergoes rigorous quality control measures, upholding the highest standards of performance and durability.



Microplate ReaderParameters:

Plate type

96- -well plate or other plates

Light source

8V/20W Halogen lamp

Filters

400nm—700nm, equipped with 4 filters: 405, 450, 492, 630nm ; 4 wavelength can be added

Resolution

0.001 Abs(Displayed),0.0001 Abs(Calculated)

Reading speed

5 seconds single-wavelength (96 wells)

Reading channel

8 channels

Calculation Method

Cut-off,ABS,1 point,Linear Reg,Semi-log poly, Poly-reg, Spline

Shaking

high, middle, low speed selectable

Display

Large touch screen LCD

Memory

up to 1 0000 test results

Printer

Built-in printer or external printer

Interface

Serial port(RS-232), parallel port(for external printer)

Dimensions

460mm(L) x 320mm(W) x 21 0mm(H)

Weight

8kg




Unlock precision and efficiency in your laboratory with our Advanced Microplate Reader. Whether you're conducting qualitative or quantitative analyses, this reader offers unparalleled accuracy and dependability, supported by our unwavering commitment to quality and technical excellence.
