Veterinary ECG Machine | 3-Channel Portable ECG

Product Overview:

MCS0171 Vet ECG Machine is a three channel digital ECG Instrument featuring simultaneous 12-lead signal acquisition. Its features include high-resolution thermal array printing system, high performance single-chip computer and large memory capacity. The advanced features make it ideal for the ECG examination in clinic and hospitals.

Key Features:

1. MCS0171 is designed with a high-resolution thermal printer featuring 8dot/mm vertical resolution and 40dot/mm horizontal resolution(at 25mm/s) speed and filter as well as related marks.
2. Simultaneously 12 lead signal acquisitions.
3. Digital filter to prevent baseline drift and automatic positioning of the baseline provide accurate ECG trace.
4. Able to detect and alarm on electrode disconnection.
5. LED indicator and LCD display show operation status of the unit.
6. Isolated input circuit guarantees safety standard in compliance to Class I type CF.
7. AC/Rechargeable battery supports continuous operation when AC power supply is not available. For the battery operation, MCS0171 is equipped with a battery charger and a system for battery capacity management and protection.
8. Compact size.

Function:

• Simultaneous printing 12 lead ECG traces of the same heat beat cycle enables prompt detection and location of ectopic premature, classification and diagnosis of arrhythmia, classification and location of WPW syndrome, diagnosis of tachycardia with broad QRS complex, as well as diagnosis of intraventricular conduction block with little tolerance.
• Simultaneous observation of ECG trace of the same heart beat cycle enables examination of detailed ECG and improvement of accuracy and precision in measurement of ECG parameters without the randomness, variant and irregularity in single lead acquisition.
• Standard measurements of ECG parameters include P wave duration, QRS duration and T wave duration, P-R interval and Q-T interval.
• Simultaneous display of ECG trace of the same heart beat cycle enables accurate judgment of ECG variant by directly comparing the 12 lead ECG trace and location of ECG trace with lower amplitude, particularly P wave, U wave and etc.
• Capable to set up ECG trace database compliant to international ECG standard for printing out accurate ECG waveform, annotation, statistic diagram and lead marks.
